Blackmagic Media Dock
Edit your URSA Cine 12K camera footage immediately after capture with Blackmagic Design’s Media Dock. The Media Dock fits three Media Modules on the front of the device, providing quick access to media from multiple cameras. The four 10G Ethernet ports can connect to four different workstations for fast editing and color grading. The device supports hot swapping of the media modules, so there’s no need to turn off the power to swap media.
You can also quickly transfer media to a computer using the USB-C port. An HDMI output lets you view media status on a monitor. The Media Dock is also compatible with cloud syncing, supporting Blackmagic Cloud, Dropbox, and Google Drive. Colored LEDs on the front let you know whether drives are mounted and not in use/read (green) or in write mode (red).
Features
Blackmagic Media Dock accelerates your post-production workflow by making it faster and easier to start editing and color grading
Attach up to three Blackmagic Media Modules for quick access to media from multiple URSA Cine cameras
The media modules are hot-swappable
With four fast 10G Ethernet ports, up to four separate editing workstations can connect directly.
Connectivity is extremely fast, even when many users are connected simultaneously
The USB-C port supports Ethernet, so you can transfer media with a simple USB-C cable connected to your computer
An HDMI output lets you view the status of your media in real time on a TV or monitor
Redundant power supply
1x Blackmagic Design Media Dock
General
Compatibility | Blackmagic Media Module |
Inputs/Outputs
USB I/O | 1 x USB-C 3.0 / 3.1 / 3.2 Gen 1 Female Input/Output |
Video I/O | 1x HDMI Monitor Output |
Other I/O | 4 x RJ45 10G |
File Format | Blackmagic (Proprietary) |
Resolution | HDMI Output: 1080p 60, 59.94, 50 |
Recording Media | 3 x Media Module Slots, Hot Swappable |
Connections | SMB: 50 Connections Maximum |
Power
Power Source | AC Input (Built-In) |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Physical
Color | Black |
Environmental Resistance | No |
Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
Storage Conditions | -4 to 140°F / -20 to 60°C up to 90% Humidity |
Cable Length | Not Specified by Manufacturer |
Dimensions | 19 x 8.11 x 3.54" / 48.3 x 20.6 x 8.99 cm |
Weight | 10.93 lb / 4.96 kg |
