Accsoon CineView Quad
The Accsoon CineView Quad Multi-Spectrum Wireless Video Transmission System lets you send a 1080p60 camera signal to the included receiver plus up to three mobile devices. The transmitter can send a 2.4 and 5 GHz signal to a total of four devices simultaneously over distances of up to 150m with only a 60ms delay, and you can transmit to any combination of receivers and iOS/Android smartphones and tablets.
The included special receiver is easy to set up and pair, and has an HDMI and SDI output. The companion app, which can be downloaded for free, can be installed on a tablet or smartphone and includes imaging tools such as peaking, zebras, false color for lighting and .cube 3D LUT overlay. The transmitter and receiver have a mains power input and they also support an optional Sony L-series battery that can power the set for up to 12 hours.
Wireless transmission
Dual band 2.4 and 5 GHz wireless transmission
Latency less than 0.06s
Long distance transmission range of 150m
One transmitter can connect up to four devices, such as receivers, smartphones or tablets
Wireless remote monitoring via Accsoon Go app
Automatic channel selection for optimal transmission
Dual image transmission over 2.4 and 5 GHz
The system simultaneously transmits two identical copies of your camera's video output on both the 2.4 and 5 GHz frequencies. When these signals arrive at the receiver, they are immediately combined to create the final high-quality video feed.
Video Input/Output
HDMI and SDI inputs on the transmitter
HDMI and SDI outputs on the receiver
Up to Full HD 1080p video and high-quality audio transmission
Design
Fanless design for quiet operation
Powered by L-series/NP-F type battery or DC input
group link button
Bright 1.3" OLED screen
Compact, lightweight design with durable aluminum construction
CineView Quad Transmitter
CineView Quad Receiver
Shoe Mount
I/O
Video | Transmitter: 1 x HDMI Type A Input |
Embedded Audio | HDMI/SDI |
power | Transmitter/Receiver: 1 x Barrel (16.8 VDC) Input |
wireless
Wireless Range | 500' / 152.4 m |
# of Channels | 20 |
Frequency Range | 2412 to 2472MHz |
latency | < 60 ms |
RF Power | 17 dBm |
WiFi | Wi-Fi 5 (802.11ac); Dual Band (2.4 & 5 GHz) |
Format Support
Video Format | HDMI/SDI/Wireless |
Timecode Support | no |
power
Battery Type | Transmitter/Receiver: 1 x L-Series |
mounting
mounting | 1 x Cold Shoe |
General
Material of Construction | aluminum |
Dimensions | Transmitter/Receiver: 4.9 x 3 x 1.2" / 12.5 x 7.7 x 3.1 cm |
weight | Transmitter/Receiver: 17.3 oz / 490 g |
