KRAMER - OSP-MM1 Optical MM 850nm 10G SFP+ Transceiver

PRODUCT OVERVIEW

OSP-MM1

Optical MM 850nm 10G SFP+ Transceiver

• Certified SFP+ optical module
• 2–strand LC–connected multimode fiber
• Ultra–reach — Up to 3km (1.8 miles) at 4K@60Hz (4:2:0)
• Data rate — 10.2Gbps

OSP−MM1 is a fiber optic transceiver for 850nm multimode signals. This standard pluggable SFP+ optical module has two LC connectors for reception and transmission of signals over two strands of multimode optical fiber.

•  Certified Transceiver — Kramer certified, hot–pluggable SFP+ optical module, for high–quality transmission of 10.2Gbps signal over multimode fiber cables, connecting 2 simplex multimode fiber strands via LC AP/UPC connectors.

APPLICATIONS

•  Optical reach extension
•  Secured signal transport

SPECIFICATIONS

OPTICAL LINE

• Multi–mode G.651.1 compliant OFNR fiber

PORTS

• 2–strand simplex fiber optic LC(PC/UPC) connector
• Note: Do not use with LC(APC) cable connectors

MAX. REACH

• 3km (1.8 miles) over OM3 MM fiber

NOMINAL PEAK WAVELENGTH

• 850nm

MAX. DATA RATE

• 10.2Gbps

TRANSMITTER TYPE

• VCSEL

OPTICAL TYPICAL TRANSMISSION POWER

• –2.5dBm

OPTICAL TYPICAL MAXIMUM RECEIVER SENSITIVITY

• –11.1dBm

OPTICAL TYPICAL MAXIMUM LOSS BUDGET

• 8.6dB

STANDARDS COMPLIANCE

• IEEE 802.3ae, SFF–8431

LASER SAFETY COMPLIANCE

• Laser Class I

REGULATORY CERTIFICATIONS

• FDA CDRH 21 CFR 1040 and Laser Notice No. 50, UL and CUL EN60950–2:2007, RoHS6, EMC EN 55022 and EN 55024

POWER CONSUMPTION

• 1W

OPERATING TEMPERATURE

• 0° to 70°C

STORAGE TEMPERATURE

• –40° to 85°C

HUMIDITY

• 5% to 95% RH
