Kramer - VS-21DTP 2x1 4K60 4:2:0 HDCP 2.2 HDMI Auto Switcher with Bidirectional PoE over HDBaseT

PRODUCT OVERVIEW

VS-21DTP

2x1 4K60 4:2:0 HDCP 2.2 HDMI Auto Switcher with Bidirectional PoE over HDBaseT

• Max. Data Rate — 8.91Gbps
• 4K@60Hz (4:2:0) resolution support
• HDMI 1.4 & HDCP 2.2 compliant
• Receiver and Provider of PoE over HDBaseT

VS−21DTP is a high−performance automatic switcher for 4K, HDBaseT, HDMI 1.4, HDCP 2.2 video signals. Offering priority and last−connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection. VS−21DTP is a PoE provider that provides power over Ethernet to compatible PoE receivers and it can also receive power from a compatible PoE provider.

•  Max. Data Rate — 8.91Gbps (2.97Gbps per data channel).
•  Max. Resolution — 4K@60Hz (4:2:0).
•  HDMI 1.4 & HDCP 2.2 Compliant.
•  Supports up to 40m reach at 4K@60Hz (4:2:0).
•  Kramer Equalization and re–Klocking Technology.
•  HDTV Compatible.
•  3D Pass–Though.
•  Bidirectional PoE over HDBaseT

APPLICATIONS

•  Classrooms
•  Huddle rooms
•  Training rooms

SPECIFICATIONS

INPUTS

• 2 HDMI: On female HDMI connectors

OUTPUTS

• 1 HDBT: On an RJ–45 connector

VIDEO

• Max. Data Rate: 8.91Gbps (2.97Gbps per graphic channel)
• Max. Resolution: 4K@60Hz (4:2:0)
• Standards Compliance: HDCP 2.2 (does not support conversion to HDCP 1.4), HDMI 1.4

USER INTERFACE

• Controls: DIP–switches for selecting switching mode (Priority/Last Connected), contact closure connectors for remote control switches
• Indicators: Active input, switching mode (Priority/Last Connected), PoE and ON

POWER

• Source: PoE over HDBaseT or 48V DC
• Consumption: 390mA

REGULATORY CERTIFICATION

• EMC EN 55032
• IEC 60950–1(ed.2)
• IEC 60950–1(ed.2)am1
• IEC 60950–1(ed.2)am2

ENVIRONMENTAL CONDITIONS

• Operating Temperature: 0° to +40°C (32° to 104°F)
• Storage Temperature: –40° to +70°C (–40° to 158°F)
• Humidity: 10% to 90%, RHL non–condensing

ACCESSORIES

• Included: 48V DC desktop power supply

PRODUCT DIMENSION

• 12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H

PRODUCT WEIGHT

• 0.2kg (0.4lbs) approx.

SHIPPING DIMENSION

• 15.70cm x 12.00cm x 8.70cm (6.18" x 4.72" x 3.43" ) W, D, H

SHIPPING WEIGHT

• 0.5kg (1.1lbs) approx.
