Aida HD-NDI3-IP67 - FHD NDI|HX3 Weatherproof Camera
Livestreaming High Frame Rate Video Everywhere, Anytime!
The HD-NDI3-IP67 is a game-changing camera that propels the boundaries of in-studio streaming, capable of displaying mesmerizing 120fps at 1080p resolution through NDI HX. With high frame rate capturing, you gain the power to slow down live footage frame by frame, resulting in captivating slow-motion sequences that will elevate any live-stream, anytime. You can also opt into something more defined, such as NDI HX3, giving you that better, better, faster video capture needed to fulfill even the most demanding of streaming requirements. Featuring a weatherproof casing, the HD-NDI3-IP67 realizes your creative vision in any environment, ensuring unparalleled reliability and performance even amidst the harshest elements.
So unleash your creativity, defy limits, and capture breathtaking moments with the HD-NDI3-IP67. So again, let’s make NDI adventurous!
MAIN FEATURES
- Full-HD 1/3” Progressive Scan CMOS sensor capable of capturing 1080p 120fps over NDI®|HX
- HX 3 Capable camera outputting up to 1080p 60fps at 60mb, 4 times the amount of HX!
- Accessible Web UI to stream directly to social media platforms and control image parameters over IP.
- Versatile design with top & bottom tripod mounts for uniques shot creation.
- Camera is PoE+ Capable. Just plug in one wire for power, control and video!
- Small form-factor and rugged designed makes all video streaming applications possible
- Small tally light on front of camera to ensure talent of when camera is live or about to be.
- Weatherproofing IP67 rating for protection against the outdoors, as well as a short submersion time under water!
Aida HD-NDI3-IP67
DC 12v Power Supply & Sockets Adapter
4mm 5MP Lens
VIDEO
Image Sensor 1/3” Progressive CMOS
Effective Pixels Horizontal: 1920, Vertical: 1080
Pixel Size 2.13 μm (H) x 2.13 μm (V)
Resolution 1080p, 1080i, 720p
Resolution Rate NDI HX ONLY: 1080 120p, 100p
- HX 3 and Others: 1080 60p/59.94/50p/30p/29.97p/25p/24p
- 1080 60i/59.94i/50i
- 720 60p/59.94p/50p
Output IP (NDI HX3/SRT/RTMP/RTSP)
Color Space 4:2:2 (YCbCr) 10bit
Min Illumination 0.2Lux (day), 0.1Lux (Night)
White Balance Auto & Manual (9000 - 11,000 K)
LENS
Lens 5MP 4mm CS Mount HD Lens
FOV: 86°
AUDIO
Audio Embed Embed over HDMI and IP streaming
Input 3.5mm Line Input
WEATHERPROOFING
IP Rating IP67 - Good against moisture, dust
PHYSICAL
Camera Control Protocol: VISCA Over IP
Operation Temp 32°F - 104°F
Dimension 120mm x 53mm x 53mm
4.72” x 2.09” x 2.09”
Weight 800g / 1.76 lb
Power 12VDC (+9 - +15VDC), PoE+ (standard IEEE802.3at)
